LIGHT SOURCE ● Light Source: 12x 80W RGBW ● Light Aux Source: 168x 1W 1800K + 168x 1W 6500K (optional) ● 8,980lm ● CRI: Ra≥72 ● CTO: 2700K-6500K ● Life expectancy: 50000hours OPTICS ● Beam angle: 2.8°-31° ● Field angle: 5°-46° ● Lux(Spot): 40,000Lux @ 5m ● Lux(Flood): 1,300Lux @ 5m ● Selectable PWM: 600Hz, 1200Hz, 2000Hz, 4000Hz，6000Hz, 25000Hz DYNAMIC EFFECTS ● Tilt: 200° ● Tilt Ranges: 60°, 180°, 200°(endcode) ● Dim Modes: 6 ● Dim Curves: 4 selectable dimming modes available CONTROL ● Protocols: DMX512, RDM, optional(Art-Net, sACN) ● Optional WDMX+CRMX(Timo FX RDM) ● Display: LCD ● Channels: 20/53/101/155/179/47/169A/169B CHs |
ELECTRONICS ● Dimmer: linear 0 ~ 100% electronic 16bit dimmer ● Strobe Rate: 0 to 25Hz ● Operating temperature: -20° ~ +45° ELECTRICAL ● Mains power supply: 90-240VAC- 50/60Hz ● Max power consumption: 900W PHYSICAL ● Housing Material: Magnesium alloy, black ● Cooling: Temp controlled, noiseless fan for forced air ● Signal connection: Seetronic XLR 5p IN/OUT ● Power connection: Seetronic powerCON TRUE1 In/Out ● IP65 RJ45 Ethernet In/Out(optional) ● USB-C: for upgrading firmware ● Dimensions (LxWxH): 1000x332x219mm ● Weight: 30.2kgs |
